Full technical parameters for the DEITY DQC2 smart battery charger, plus the built-in protection features that safeguard your batteries and the charger. All data was measured by DEITY Audio Laboratory and is subject to actual data.
Specifications
| Model | DEITY DQC2 smart battery charger |
| Color | Black |
| Applicable battery | Suitable for the DEITY S-95 (98Wh) smart battery, including all commercially available smart batteries. Please use half-charge mode for S-95 batteries with half capacity. |
| Charging protocol | Complies with PD3.0 and Type-C V1.4 specifications, and also supports Apple divider 3, BC1.2 SDP, CDP, and DCP charging protocols. |
| Input power | A charger greater than 100W is recommended. Chargers less than 100W can also be used but will affect the charging experience. |
| Input parameters | Dual USB-C: 5V/3A, 9V/3A, 12V/3A, 15V/3A, 20V/5A (Max 100W) |
| Output parameters | USB-A: 5V/2A. Dual BAT: S-95 battery charging (Max 50W) |
| Product size | 124 x 95 x 39 mm |
| Working temperature | 0 to 55C |
Tip: the illustrations in this manual are for reference only. Due to the continuous development of new product versions, if there is any discrepancy between the product and the illustrations, please refer to the product itself.
Protection Features
The DQC2 is engineered to protect both your batteries and the charger with a full suite of safety protections.
- Overcharging protection
- Overcurrent protection
- Overdischarge activation
- Short circuit protection
- Overvoltage protection
- Overpower protection
- Restoration protection
- Electromagnetic field protection
- Over temperature protection
